the breakdown

Technical drawing or diagram showing a cross-sectional view of a flag or marker placement in a designated area. It includes labeled markings such as 'In-ground FATO Edge Marking,' 'Painted TLOF Edge Marking,' and 'Safety Area,' with dimensions noting a 12-inch wide strip and distances of 5 feet each for mark placement. The diagram details surface markings, edge markings, and layout specifications for a controlled aircraft or helicopter landing area.

Zephyr Aviation Coatings proudly offers professional services nationwide.

Once we are in communication with our client, we will schedule a site visit to ensure an accurate estimate.

Dimensions & site visit

View of a rooftop with a large sports logo painted on it, featuring a red star, a yellow circle, and a white background, with trees and buildings in the background.

Choose your product

We offer two durable options:

  1. A two-component, high-solids, fast drying polyamide epoxy mastic. In which we would use for the entirety of the Helipad surface and FAA markings.

  2. An resilient stick-on sheet with the FAA markings printed on it. This same product is on marine vessels, where the conditions are wet, cold, and harsh. With this option, we start by painting on a base coat of the epoxy explained above, then the Stick-on FAA markings are applied.

Close-up of a gray textured coating with small light-reflecting speckles.

Choose your grit

Once the Helipad is coated and marked, we apply a clear coat that adds an additional layer of protection.

It is in this clear coat we add grit which makes the pad a non-slip surface.

We can send you samples of the different levels of grit.

Contact us
